High Strength Wire Rope Mesh Protective Net 7x7 / 7x19 / 1x19 CE Approved

Name: High Strength Wire Rope Mesh Protective Net 7x7 7x19 1x19 CE Approved
Brand: Yuntong
Price: 1 USD

Wholesale High Strength Wire Rope Mesh Protective Net 7x7 / 7x19 / 1x19 CE Approved from china suppliers

Brand Name : Yuntong

Model Number : YT--F-F

Certification : CE , SGS

Place of Origin : Hebei

MOQ : 10 Sqm

Payment Terms : T/T, Western Union,PayPal

Supply Ability : 300Sqm/Week

Delivery Time : 5-8 Work Days

Packaging Details : Package film for each piece,Several pieces packed in 1 carton

Product Name : Wire Rope Mesh Netting

Material : AISI316 , AISI316L

Rope Constructions : 7 x 7 , 7 x 19 , 1 x 19

Mesh Type : Ferruled or Knotted

Mesh Orientation : Horizontal , Vertical

Wire Rope : 1.2 mm to 4.0 mm

Finished : Ultrasonic Bath , Black Oxide

Mesh Shape : Rhombus , Diamond

Contact Now

High Strength Protective Stainless Steel X Tend Wire Rope Mesh Webnet

Wire Rope Mesh Specifications Sheet :

Hole Size (Opening)	1.2MM(3/64) (7 x 7 )	1.6MM(1/16) (7 x 7 )	2.0MM(5/64) (7 x 7 )	2.4MM(3/32) (7 x 7 )	3.2MM(1/8) (7 x 19 )
20 x 35mm	YT-1235
25 x 42mm	YT-1225	YT-1625
30 x 52mm	YT-1230	YT-1630	YT-2030
35 x 60mm	YT-1235	YT-1635	YT-2035
38 x 66mm	YT-1238	YT-1638	YT-2038	YT-2438
40 x 69mm	YT-1240	YT-1640	YT-2040	YT-2440	YT-3040
50 x 86mm	YT-1250	YT-1650	YT-2050	YT-2450	YT-3050
60 x 104mm	YT-1260	YT-1660	YT-2060	YT-2460	YT-3060
70 x 120mm	YT-1270	YT-1670	YT-2070	YT-2470	YT-3070
76 x 131mm	YT-1276	YT-1676	YT-2076	YT-2476	YT-3076
80 x 138mm	YT-1280	YT-1680	YT-2080	YT-2480	YT-3080
90 x 154mm	YT-1290	YT-1690	YT-2090	YT-2490	YT-3090
100 x 173mm	YT-12100	YT-16100	YT-20100	YT-24100	YT-30100
120 x 206mm	YT-12120	YT-16120	YT-20120	YT-24120	YT-30120

SS304	(%) C:≤0.07, Si :≤1.0, Mn :≤2.0, Cr :17.0-19.0, Ni :8.0-11.0, S :≤0.03, P :≤0.035
SS316	(%) C:≤0.08, Si:≤1.00, Mn:≤2.00, P≤:0.035, S:≤0.03, Ni:10.0-14.0, Cr:16.0-18.5
SS316L	(%)C:≤0.03, Si:≤1.00, Mn:≤2.00, P:≤0.045, S:≤0.030, Cr:16.0～18.0, Ni:12.0～15.0

The wire rope mesh is manufactured in the standard diameters 1.0 mm, 1.5 mm, 1.6mm, 2.0 mm, 3.0 mm and 3.2mm.Mesh width of 25 to 200 mm (or bigger) are possible depending on cable diameter.
Rope Mesh is manufactured from high-grade stainless steel cables of material class 1.4401, AISI316.

Mesh connections (ferrules) are available in highly aesthetic stainless steel for premium applications or where resistance to corrosion is a driving consideration.

Finished diamond mesh style when it is stretched at 60 degree angle ;

Mesh can be applied in either a vertical or horizontal direction, again dependent on the balustrade or railing design and the required aesthetics.

Our services range from ferruled wire rope mesh , knotted wire rope mesh to various installation's accessories . Also we can provide black oxide wire rope mesh .

High Strength Wire Rope Mesh Protective Net 7x7 / 7x19 / 1x19 CE Approved

Characteristic

Custom-Manufactured
Discrete, elegant and flexible.
Multifunctional, and compatible with creative architecture.
Premium Quality, Rugged , Weather-Resistant , Non-Corroding and Corrosion-resistant, Alkali Resistant

High Strength Wire Rope Mesh Protective Net 7x7 / 7x19 / 1x19 CE Approved
